PTFE Hose Tube

• Brand:WITFLON
• Product origin:Hubei,China
• Delivery time:3~7 Days
• Supply capacity:10Ton/Day

keyword:

ptfe line pipe ptfe teflon tube ptfe extruded tubing virgin ptfe tube large diameter ptfe tube

Classification:

PTFE Hose Tube

Send Email:

rose@wentaiptfe.com

Inquiry Now

More Products

Products Details

Hubei Wentai New Material Co.,ltd is a professional manufacturer and supplier of ptfe products such as kinds of PTFE tubes,PTFE rod,PTFE board,PTFE beaker,multi-lumen PTFE tube,FEP tube,and PFA tube etc.

We are dedicated to offering you superior quality products and efficient services at competitive prices. We aim to achieve customer satisfication at all levels. Consolidated orders are accepted and prompt delivery is guaranteed.

For more information, contact us today !

• Brand:WITFLON

• Product origin:Hubei,China

• Delivery time:3~7 Days

• Supply capacity:10Ton/Day

Features:
• Features:

• Low and high temperature resistance

• Corrosion resistance

• Wear resistance

• Insulation resistance

• Acid and alkali resistance

• Low friction

• Non-acid

• Excellent electric properties

Technical Data
Name	PTFE	FEP	PFA
Tensile Strength(kp/cm²)	250	210	280
Extensibility(%)	350	300	300
Hardness(D)	55D	D55	D55
Melting point(℃)	327	279	305
High temperature(℃)	+260	+200	+260
Low temperature(℃)	-200	-200	-200
Non combustion limit	Rated 94 vo	Rated 94 vo	Rated 94 vo
Water uptake(20℃,%)	<0.01	<0.01	<0.01
Weathering resistance	Excellent	Excellent	Excellent
Density(g/cm³)	2.1	2.1	2.1
1Mhz Permittivity	2.1	2.1	2.1
Dissipation Factor	0.0002	0.0002	0.0002
Resistance to organic	Excellent	Excellent	Excellent
Engage in acid-base properties	Excellent	Excellent	Excellent
elasticity	Good	Good	Good
Specific heat cal/g/	0.3	0.28	0.29

Capillaries

PTFE Hose Tube Size List
Size	ID(mm)	OD(mm)	W/T（mm)	Tolerance（mm)	Packing(m)
1*2	1mm	2mm	0.5mm	±0.05	100m/Roll
2*3	2mm	3mm	0.5mm	±0.1	100m/Roll
2*4	2mm	4mm	1mm	±0.1	100m/Roll
3*4	3mm	4mm	0.5mm	±0.1	100m/Roll
4*5	4mm	5mm	0.5mm	±0.15	100m/Roll
4*6	4mm	6mm	1mm	±0.1	100m/Roll
4.35*6.35	4.35mm	6.35mm	1mm	±0.1	100m/Roll
5*6	5mm	6mm	0.5mm	±0.1	100m/Roll
5*7	5mm	7mm	1mm	±0.15	100m/Roll
5*8	5mm	8mm	1.5mm	±0.15	100m/Roll
6*7	6mm	7mm	0.5mm	±0.01	100m/Roll
7*8	7mm	8mm	0.5mm	±0.15	100m/Roll
6*8	6mm	8mm	1mm	±0.15	100m/Roll
6*9	6mm	9mm	1.5mm	±0.15	100m/Roll
6.35*9.53	6.35mm	9.53mm	1mm	±0.2	100m/Roll
6*10	6mm	10mm	2mm	±0.2	100m/Roll
7*9	7mm	9mm	1mm	±0.2	100m/Roll
7*10	7mm	10mm	1.5mm	±0.2	100m/Roll
7*11	7mm	11mm	2mm	±0.2	100m/Roll
8*9	8mm	9mm	0.5mm	±0.2	100m/Roll
8*10	8mm	10mm	1mm	±0.2	100m/Roll
8*11	8mm	11mm	1.5mm	±0.2	100m/Roll
8*12	8mm	12mm	2mm	±0.25	100m/Roll
9*10	9mm	10mm	0.5mm	±0.2	100m/Roll
9*11	9mm	11mm	1mm	±0.2	100m/Roll
9*12	9mm	12mm	1.5mm	±0.2	100m/Roll
9.6*12.7	9.6mm	12.7mm	1.5mm	±0.2	100m/Roll
10*11	10mm	11mm	0.5mm	±0.15	100m/Roll
10*12	10mm	12mm	1mm	±0.2	100m/Roll
10*13	10mm	13mm	1.5mm	±0.25	100m/Roll
10*14	10mm	14mm	2mm	±0.25	100m/Roll
11*12	11mm	12mm	0.5mm	±0.2	100m/Roll
11*13	11mm	13mm	1mm	±0.2	100m/Roll
12*14	12mm	14mm	1mm	±0.2	100m/Roll
12*16	12mm	16mm	2mm	±0.3	100m/Roll
13*15	13mm	15mm	1mm	±0.2	100m/Roll
14*16	14mm	16mm	1mm	±0.25	100m/Roll
14*17	14mm	17mm	1.5mm	±0.3	100m/Roll
14*18	14mm	18mm	2mm	±0.3	100m/Roll
15*17	15mm	17mm	1mm	±0.2	100m/Roll
16*18	16mm	18mm	1mm	±0.2	100m/Roll
16*19	16mm	19mm	1.5mm	±0.3	100m/Roll
16*20	16mm	20mm	2mm	±0.3	100m/Roll
18*20	18mm	20mm	1mm	±0.3	100m/Roll
18*21	18mm	21mm	1.5mm	±0.3	100m/Roll
18*22	18mm	22mm	2mm	±0.3	100m/Roll
19*21	19mm	21mm	1mm	±0.3	100m/Roll
19*22	19mm	22mm	1.5mm	±0.3	100m/Roll
19*23	19mm	23mm	2mm	±0.3	100m/Roll
20*22	20mm	22mm	1mm	±0.3	100m/Roll
20*23	20mm	23mm	1.5mm	±0.3	100m/Roll
20*24	20mm	24mm	2mm	±0.3	100m/Roll
20*25	20mm	25mm	2.5mm	±0.4	100m/Roll
21*25	21mm	25mm	2mm	±0.3	100m/Roll
22*24	22mm	24mm	1mm	±0.3	100m/Roll
22*25	22mm	25mm	1.5mm	±0.3	100m/Roll
23*25	23mm	25mm	1mm	±0.3	100m/Roll
24*26	24mm	26mm	1mm	±0.3	100m/Roll
25*27	25mm	27mm	1mm	±0.3	100m/Roll
25*28	25mm	28mm	1.5mm	±0.3	50m/Roll
25*29	25mm	29mm	2mm	±0.3	50m/Roll
26*28	26mm	28mm	1mm	±0.3	50m/Roll
28*30	28mm	30mm	1mm	±0.4	50m/Roll
32*36	32mm	36mm	2mm	±0.5	50m/Roll
38*42	38mm	42mm	2mm	±0.5	50m/Roll
44*48	44mm	48mm	2mm	±0.5	50m/Roll
47*51	47mm	51mm	2mm	±0.5	50m/Roll
50*54	50mm	54mm	2mm	±0.5	20-30m/Roll
51*55	51mm	55mm	2mm	±0.5	10-20m/Roll
56*60	56mm	60mm	2mm	±0.5	10m/Roll
60*64	60mm	64mm	2mm	±0.6	10m/Roll
77*81	77mm	81mm	2mm	±1.1	10m/Roll
74*82	74mm	82mm	4mm	±1.1	Customized
77*82	77mm	82mm	2.5mm	±1.1	Customized
98*103	98mm	103mm	2.5mm	±1.5	Customized
150*160	150mm	160mm	5mm	±2.1	Customized

Capillaries

Q.Are you trading company or manufacturer?
We are professional PTFE product manufacturer with IATF16949, ISO14001 certificated, and all material are RoHS compliant.

Q.Do you accept OEM?
Yes,we could print your logo if reach our MOQ.

Q.How about your packing?
WITFLON: 3layer packing, Inner plastic bags, packed in carton box and wooden packang for heavy goods. Keep your good away from water.

Q.How does your factory do regarding quality control?
"Four Steps" QC:
(1) Workers self inspecting,
(2)workshop inspector inspecting,
(3)packing inspecting
(4) finished goods random inspection in warehouse before delivering.

Q.Can I get some samples?
We are honored to send you our samples, but the express fee needs to be paid by your esteemed company.
